Our Traction Machine Roomless (MRL) solution is equipped with a premium quality gearless motor and a state of the art inverter that lead to an outstanding ride quality, eliminate noise and achieve very low energy consumption. Furthermore, all lift components are cleverly designed to achieve efficient use of space inside the shaft as well as ease of installation and maintenance.
Advantages:
- Premium ride quality through state of the art technology
- High energy efficiency (especially for high-rise buildings)
- Compact Design and Ease of installation
- Minimal requirements for pit and headroom dimensions.
- Single Phase lift operated on 230volts.
- Eco- friendly.
Traction MRL Passenger Lifts Specification:
| Usage | |
| Advantages | Premium ride quality through state of the art technology.It reduces the building expense and saves the construction cost too. |
| Rated Loads (Persons/kg) | 5/375 - 13/1050 |
| Machine Room | None |
| Maximum Travel | 70 |
| Maximum Stops | 24 |
| Car Speed (M/s) | up to 1.6 |
| Motor Type (Drive) | Gearless VVVF |
| PIT Depth (Minimum) | 1300 |
| Headroom (Minimum) | 3600 (max u=1.0mps) / 3700 |
| Maximum Car Entrances | 3 |
